Sailing Page - 2

Builder: Catalina Yachts Model: Catalina 320 Rigging: Sloop LOA: 32' 6" LWL: 23' 10" Beam: 11' 9" Draft: Wing Keel 4' 3" Displacement Wing Keel: 11,700 lbs. Ballast: Wing Keel - 4400 lbs. Sail Area (100% foretriangle): 521 sq ft Hull Speed with engine: 7 knots Mast Height, from waterline: 47' 7" Head Room: 6' 3" STANDARD EQUIPMENT Sails: 135% Furling Genoa, Dacron with U.V. Protection. Mainsail-Dacron with reef, full battens and Dutchman Flaking System. Internal Halyards, Low Stretch.

  Spars and Rigging:
  Annodized mast and boom. Double spreader rig with stainless steel
  standing rigging, stainless rigid boom vang, traveler on cabin roof
  with multiple purchase adjustment and bilateral main sheet;
  Inboard genoa tracks; self-tailing primary and secondary winches;
  all lines lead to cockpit. Internal halyards; adjustable outhaul.

  Propulsion, Steering, and Controls:

  40" S/S Destroyer wheel on Edson pedestal, with Brake, Engine Controls.
  Danforth 410 5" illuminated Compass on Pedestal; stainless guard.

  Yanmar 30hp Diesel Engine, 3 cylinder with Fresh Water Cooling, Engine
  Panel with tachometer, gauges, and alarm system. 3 Blade Propeller.
  Bilge blower. Speed and Depth gauges on the pedestal.
  Features and Deck Hardware:

  Walk through Transom with Removable Helm Seat. Stern boarding ladder
  with contoured treads. Double rail safety lines; s/s bow and stern
  pulpits, double rail. Stern rail observation seats port/starboard.
  Anchor locker on foredeck with roller stem fitting and electric
  windless. Lead keel, winged, with s/s bolts.

  3 Fixed Ports in Hull; Solid Teak Hatch Boards. Stainless Steel
  Handrails on Cabin Top. Coaming Compartments port/starboard. Self
  Bailing Cockpit. Molded in non skid surfaces. Complete inner hull
  liner. Lazarette locker and cockpit seat locker.


  Varnish finish on interior. Teak veneer bulkheads & teak interior trim.
  Teak and holly sole. Cabin doors on fore and aft cabins. Ventilation
  deck hatch in main cabin and forward cabin, aluminum framed. Navigation
  table with storage and navigation light.

  Sleeping Berths for seven. Traditional teak dining table, adjustable.
  Hanging locker with bureau. Cabin window shades. Screens for opening
  ports and hatches.


  Aft galley with two s/s sinks, ice box, and storage. Custom molded
  counter tops. Two burner gimbaled stove with oven, L.P.G. with auto
  ignition. Refridgeration system, D.C. powered.

  Plumbing System:

  Hot and cold pressure system with outlet in head, galley and cockpit.
  Marine head with macerator pump, holding tank and deck discharge outlet.
  Manual bilge pump and Electric bilge pump. Hot/cold shower on the

  Electrical System:

  Marine battery charger. Anchor light on masthead. Steaming and Deck
  light on mast. Cabin and navigation lights. Battery condition meter.
  DC electrical system with two batteries. Selector switch and panel with
  circuit breakers. A.C. Dockside power with (5) outlets.

Tankage And Capacities:

Cold Water: 26 gal foreward, 20 gal port.
 Hot Water:  6 gal in heater. Total = 52 gal

Diesel Fuel: 20 gal
Holding Tank: 12 gal
Ice box: 5.8 cubic feet.
